Collection: Temperature Control Panels

Custom-Built for Precision Process Heating

Our made-to-order Temperature Control Panels are engineered for reliable, precise operation across a wide range of process heating applications. Each panel is fully factory pre-wired, eliminating the need to design or assemble your own system—simply install and connect.

Typical Uses: Chemical coating, circulation heaters, drying and curing ovens, duct heaters, fuel heating, heat-treating, holding tanks, paint curing, thermoforming, and waste-reduction systems.

Key Features:

  • Choice of advanced temperature controllers (N1030 PID or N1050 process controller) with dual display and auto-tune

  • Start/stop rotary switch

  • Circuit breaker or fused disconnect options with high-level overcurrent protection (up to 200 kA)

  • Main & heater power up to 600 VAC three-phase

  • High-limit safety contactor, power-on indicator lamp

  • Fused control transformer, labelled terminal blocks

  • Hardwired power and sensor connections

  • Ventilation fan, filter, or ambient heater options

  • Audible/visual alarm capability

  • Optional twist-lock or jack-panel external connections

Heater Power Output:

Solid state relays per fused sub-circuit, available from 50A to 100A, suitable for circulation heaters, duct heaters, and other resistive loads. Systems available with SCR controls, SSRs, or mechanical contactors.
