WAGO Type 221 5-Way Connector – 32A, Lever Wire Connector Block

Description

The WAGO Type 221 5-Way Connector (32A) provides a reliable, tool-free solution for connecting up to five wires quickly and securely. Using its intuitive lever mechanism, simply lift the lever, insert the conductor, and push it back down for a strong, vibration-resistant joint.

Its compact, transparent housing allows for easy inspection of connections, while the five-pole configuration is perfect for distributing power to multiple wires from a single point. Durable, reusable, and designed for both commercial and domestic applications, this connector saves time and ensures dependable results.

Key Features

• Quick lever-action design for tool-free wiring

• Connects up to 5 wires in one compact block

• Transparent housing for safe and easy inspection

• Rated for 32A at 450V

• Suitable for solid, stranded, and flexible conductors

• Reusable for both permanent and temporary setups

Technical Specifications

Electrical:

• Voltage Rating: 450V AC / 600V (UL)

• Current Rating: 32A

• Contact Resistance: ≤ 20 mΩ

• Insulation Resistance: ≥ 1000 MΩ @ 1000V

• Dielectric Strength: 2500V AC for 1 min

Mechanical:

• Wiring Range: 0.2 – 4mm² (24–12 AWG)

• Stripping Length: 10–11mm

• Operating Temperature: -45°C to +105°C

Construction Materials:

• Cover: PC (Polycarbonate)

• Body: PA66 UL94 V-0 (Flame Retardant)

• Spring: SUS 301 Stainless Steel

• Conductor: Copper, Tin-Plated

• Button/Lever: PA66

Applications

• Distribution of power to multiple wires

• Domestic and commercial wiring projects

• Junction boxes and control panels

• Lighting installations

• HVAC and industrial electrical systems

✅ SEO Meta Details

Meta Title:
WAGO Type 221 5-Way Connector – 32A Lever Wire Connector Block

Meta Description:
Shop WAGO Type 221 5-way connectors, rated 32A 450V. Connect up to five wires securely with lever-action design. Compact, reusable, and perfect for junction boxes & lighting.

URL Slug:
/wago-221-5-way-connector-32a-lever-wire-block

Now you have 2-way, 3-way, and 5-way connectors all with matching structure, SEO titles, and descriptions — strong for category SEO and product clarity.

👉 Do you want me to now write a collection page description for “WAGO 221 Series Connectors” to tie all of these together into one optimised landing page?

WAGO type 221 Connector 32A 5-way connectors.
WAGO type 221 Connector 5-way 32A is a simple and easy way to connect and disconnect cables and wires. By opening the lever and inserting the lead then pushing it back into place. They allow for speed and ensure a positive connection always.

SPECIFICATIONS

1.Material:
①Cover:PC
②Body:PC
③Spring:SUS3
④Conductor:Copper (Sn PLATED)
⑤Button:PA66
2.Voltage rating/Current rating:450V /32A;
3.Wiring Range:0.2-4mm²
4.Contact resistance:20 mΩMax；
5.Stripping length:11mm；
6.Poles:2,3,5；

Technical Data

Material:
Electrical:
Voltage rating/Current rating:IEC 600V/32A;
Contact resistance:20 mΩMax.
Insulation resistance:1000V,1000 MΩMin.
Withstanding Voltage: AC 2500 V,1 minute.
Mechanical:
Stripping Length:10mm.
Connection Capacity:24-12AWG.
Operating temperature:-45°C to +105°C.
Body: PA66 UL94 V-0.
Conductor: Copper, Tin Plated.
Spring: SUS 301.
UL 450V/32 A
