Three-Zone Temperature Control Panel – Single or Three Phase

The three-zone temperature control panel is a cutting-edge solution designed for precise and dependable management of heating circuits. This panel is particularly advantageous for process heating applications in various settings. With options for both single-phase and three-phase, it caters to a diverse range of industrial and commercial heating systems.

Key Features

• Three Heating Zone Control: This feature allows for the meticulous regulation of three separate heaters or heating circuits, ensuring optimal performance.
• Single-Phase or Three-Phase Options: The panel is versatile and can accommodate different power needs and heater types, making it a preferred choice for various applications.
• Output Type: Equipped with a Solid-State Relay Output rated for 50A (max operating load per zone 25A), it guarantees reliability during operation.
• Input Type: Utilises a Type K thermocouple for accurate temperature readings.
• Advanced Temperature Controller: Features PID or process controller options, complete with a dual digital display for enhanced information accessibility, coupled with auto-tuning capabilities.
• Built-In Safety Protection: A high-limit safety contactor, overcurrent protection, and an indicator for power-on status ensure safe operation.
• Factory Pre-Wired Design: Arriving fully assembled and wired, this panel facilitates quick installation and reliable performance.
• Durable Industrial Build: This panel is designed to perform well in various applications such as circulation heaters, duct heaters, immersion heaters, and tank heating, supporting a variety of resistive loads.
• Panel Dimensions: The single-phase option measures 650x250x900mm, while the three-phase variant is 650x250x1150mm.

Applications

This three-zone temperature control panel is perfect for industries requiring consistent heating solutions across processes, including applications in tanks, ovens, dryers, and thermoforming equipment. Its advanced features make it ideal for any setting that emphasises process temperature control.
